Product description: 4*HDMI Uncompressed Video Fiber Optic Transmission
INQUIRY

CJ-3001H-4V is a set of extender device of high-definition video transmission which use fiber optic, just need a single fiber will be able to transmit 1080p signal over long distances, it support audio transmission. This product is ideal for large-screen display, conferencing systems and home entertainment and so on. The device has the ability of anti-interference, to ensure the stability of the signal.

Feature：

● Provide 4 channel uncompressed high definition HDMI(DVI) video

● Compliance with HDMI1.3 standard

● Support HDMI signal input or output
● HDCP1.2
● The Transmitter support the transmission of the HDMI audio and the independent stereo
● The Receiver support the output of the HDMI audio and the Independent stereo
● Support 1080p 60H, single mode fiber transmission up to 10 KM
● Real-time transmission of high-definition uncompressed digital HDMI video signal, the video is clear and stable
● Built-in ESD protection circuitry, can effectively prevent electrostatic damage
● Site installation: easy, plug and play, no need to set

● Support serial unidirectional transmission, baud rate adaptive

4 channel HDMI Uncompressed Video Fiber Optic Transmission

4 channel DVI Uncompressed Video Fiber Optic Transmission

Order information:

Model	function
CJ3001H-4V	Single mode single fiber FC \ 20KM, 4 channel HDMI video, 4 channel audio
CJ3001D-4V	Single mode single fiber FC \ 20KM, 4 channel DVI video, 4 channel audio
CJ3001H-2SV	Single mode single fiber FC \ 20KM, 2 two-way HDMI video, 2 two-way audio
CJ3001D-2SV	Single mode single fiber FC \ 20KM, 2 two-way DVI video, 2 two-way audio
